Features
■ Interior
20 gauge stainless steel. 12” or 15” deep
■ Cold Plate
Cast aluminum post mix plate with 10 circuits. Plate is sealed into
bottom. Each circuit is 5/16” OD stainless steel tubing. Two full with
remainder to be half circuits. Bump and swedge fittings on ends
■ Front Apron
20 gauge stainless steel clad over 20 gauge galvanized steel
■ Backsplash
20 gauge stainless steel
■ Back and Bottom
20 gauge galvanized steel
■ Legs
1 5/8” tubular 16 gauge stainless steel with grey plastic bullet foot
■ Tubing Access (Cold Plate)
1800 Series: 3/4” x 3 1/2” cutout in left side of backsplash
2100 Series: 1/2” x 4.3” cutout in left side of backsplash
■ Insulation
Foamed-in-place polyurethane
■ Plumbing
Cold Plate: 1/2” IPS drain connection
No Cold Plate: 1” IPS drain connection
■ NOTE: Cold Plate units supplied with 1/2” x 4” male
threaded PVC tailpipe
Features
Mount Type
Backsplash Height
Cold Plate Circuits
Capacity
Ice Capacity
Bin Size Side to Side
Bin Size Front to Back
Bin Depth
Material & Finish
Material
Steel Gauge
Dimensions
Length
24 in
Width
19 in
Height
36.50 in
Weight
158 lb
Ship Freight Only
Yes
